Rice Lake Master Series BS14 Belt Scale Systems

Belt Scale Systems BS14

 https://www.ricelake.com/product-landing-pages/belt-scale-systems/

Applications

• Mines
• Metalliferous Mining operations
• Coal Mining operations
• Ore Beneficiation processes
• Crushing Plants
• Sand & Gravel Operations
• Overland Conveyors
• Coal Fired Power Plants
• Rail Loadouts
• CHPP Plants
• Cement Mills

Rice Lake Master BS211 Belt Scale System

Belt Scale Systems

We proudly supply the Rice Lake Master Series 211 precision belt scale system that consists of an inner frame mounted with two friction-free pivots to one end of the scale. The load cell is located on the opposite end with the idler mounted on the inner frame. Therefore, the friction-free pivots absorb tensile stress in a horizontal direction. This creates a very solid weigh frame that is well-suited for heavy-duty applications that you can trust.

The BS211 is designed to monitor feed to crushers, mills, screens and other processes as well as regulate product loadout with an accuracy up to ±0.5%.

https://www.ricelake.com/products/master-211-belt-scale-weigh-frame/

Applications

• Medium to Heavy Capacity, mining, process and agriculture
• Chemical plants, Asphalt plants, Mines, Cement mills, Coal preparation plants
• Paper mills, Gypsum mills, Sand and gravel operations
• Coal-fired power plants
• Ore beneficiation processes

Discover the Rice Lake Master Precision Belt Scale for time proven heavy-duty design that is perfect for challenging applications. The intuitive Integrator makes set-up and calibration, with on-board diagnostics, easy to use. Contact our Sales team today.

Rice Lake Weigh Belt Feeders

Precision Weigh Belt Feeders

Control the flow of product with Rice Lake Weigh Belt Feeders that are now available through Minprovise. With guaranteed accurate and consistent weight output for a wide variety of industries and applications.

The complete system comes with either model WE503D or 1280 Enterprise Controllers.

https://www.ricelake.com/product-landing-pages/weigh-belt-feeders/

 Applications

• Mining
• Bulk Material Blending
• Food Industry
• Process Control
• Many more ….

Discover a variety of belt conveyors, weigh belts and weigh-belt feeders available, as well as different applications and industries. Talk to our Sales Team today.

Rice Lake Master Belt Scale Weigh Frame

Belt Scale Weigh Frame BS221DB

We proudly supply 221DB Master™ belt scale weigh frame manufactured by Rice Lake Master. This frame consists of two arms that are equipped with a pivot and a load cell mounted to the side supports of the conveyer belt. The idler, or weighing roller, is mounted on top of the frame arms.

The 221DB is easy to assemble and access to service. Being suitable for most belt widths and capacities, the 221DB is a versatile solution for many applications with an accuracy of ±0.5% to 1.0%, even in the harshest applications.

This belt scale weigh frame enables you to monitor production output and inventory, or regulate product loadout, while providing vital information for the effective management and efficient operation of your business.

https://www.ricelake.com/products/master-221db-belt-scale-weigh-frame/

https://www.diniargeo.com/images/newsletter/master/master_en.html

Applications

• Medium to Heavy Capacity.
• Chemical plants
• Asphalt plants
• Mines
• Cement mills,
• Coal preparation plants
• Paper mills
• Gypsum mills
• Sand and gravel operations
• Ore beneficiation processes

Specifically designed for general in-plant belt conveyor weighing applications in the most demanding industrial environments.  Discover the Rice Lake Master Belt Scale Weigh Frame Series BS221DB by contacting our Sales Team today.

Rice Lake Master Screw Weigh Feeders

Screw Weigh Feeder

Minprovise proudly supplies Rice Lake Screw Weigh Feeder, so whether an existing or new-to-build screw conveyor, install a new screw weigh system, and effortlessly create in-line measurement without disturbing the product flow.

A complete Screw Weigh Feeder includes a weigh frame, load cell, junction box, speed pickup and screw conveyor. It also comes with either model WE503D or 1280 Enterprise Controllers.

https://www.ricelake.com/product-landing-pages/screw-weighers/

To elevate efficiency with Rice Lake Screw Weigh Feeder, contact our Sales Team today.

Rice Lake Master BulkSlide Solids Flow Meter

Precision Flow Meter

We are proud to supply the Rice Lake Master BulkSlide. This is a solids flow meter that measures with precision and speed to a high accuracy from ± 0,5 percent.  It can be used for most solid bulk products that are free flowing and non-sticky.

Flow meters offer a compact and efficient design for use in a variety of spaces and applications, including explosive and hazardous environments.

The Complete system consists of the IFM30 sensor, IFP30 sensing plate, IFH30 housing and flow meter integrator (model WE503D).

https://www.ricelake.com/product-landing-pages/flow-meters/

Contact our Team today.

Rice Lake Impact Flow Meters Model IFM30

Impact Flow Meter

Minprovise are proud to supply the Rice Lake Model IFM30 Impact Flow Meter with an accuracy level of ± 0,5 % to 1.0 %. Applications include most solid bulk products that are free flowing and non-sticky.

This Impact Flow Meter offers a compact and efficient design that can be used in a variety of spaces and operations including explosive and hazardous environments.

https://www.ricelake.com/product-landing-pages/flow-meters/

Purchase the complete system today, consisting of the Flow Meter Model IFM30 sensor, IFP30 sensing plate, IFH30 housing and flow meter integrator WE302D. All available from Minprovise, so talk to our Sales Team today.

Rice Lake Loss in Weight Feeders

Loss-In-Weight Feeders

Discover ideal dosing systems for a variety of applications with Rice Lake Master Weighing Systems, now proudly supplied by Minprovise. Loss-In-Weight Feeders are ideal dosing systems for bulk product, dry and liquid materials and even poorly flowing materials.

Loss-in-weight feeders consist of a hopper with a dosing unit—typically a screw or vibrating unit—placed on load cells monitoring the material output during dosing. The dosing-unit hopper can be refilled manually or automatically from a storage hopper without impacting the dosing rate or stopping production.

Dosing is typically measured in kilograms per hour and a digital controller adjusts the speed of the dosing unit to match the setpoint, ensuring consistent product flow.

https://www.ricelake.com › products › loss-in-weight-f

Whether used in food or chemical production, high temperature or ATEX environments, Rice Lake Weighing Systems has a loss-in-weight feeder to meet your requirements. Talk to our Sales Team today.

Rice Lake Speed Sensor

Speed Sensor

Enhance monitoring with our premium Speed Sensor. Directly coupled to rotating shafts, it delivers a digital pulse output signal proportional to shaft speed for accurate data.

https://www.ricelake.com/products/speed-sensor/

Typically, the Rice Lake Speed Sensor is installed on the non-driven pulley of a belt conveyor, enabling it to detect the belt speed for applications such as belt scale, speed monitor, or PLC. Contact our Sales Team today for more information or to purchase.

Rice Lake Master WE503D Integrator/Controller

WE503D Belt Scale Integrator/Controller

Discover the Rice Lake Master WE503D Belt Scale Integrator/Controller. This sophisticated piece of equipment is used for dynamic weighing systems including:

• Belt Scales,
• Screw Weighers
• Bulkslide Flow Meters
• Impact Flow Meters

https://www.diniargeo.com/images/newsletter/master/master_en.html

The WE503D delivers an electronics package that is packed full of features and comes in an IP69 SS Enclosure with LCD screen, and multiple protocol types. It delivers high end performance for today’s operational requirements. The WE503D also offers many expansion options for future optimisation and growth. Talk to our Sales Team today.

Rice Lake 1280 Enterprise Series Integrator/Controller

1280 Enterprise™ Series Programmable Weight Indicator and Controller

Minprovise proudly supplies the Rice Lake Master 1280 Enterprise Series programmable digital Weight Indicator and Belt Scale Controller.

Features include a customisable colour touchscreen with graphical user interface, web server view for remote access and multiple protocol types to deliver uncompromising speed for today’s operations as well as expansive options for tomorrow’s requirements. To see full features and benefits click the link below.

https://www.ricelake.com/products/1280-enterprise-series-programmable-weight-indicator-and-controller/

Contact our Sales Team today about how this premium product can optimise your operation.

Apron Feeders

Combining the Best Design Features into One Solution

The experience and knowledge gained from decades of working with apron feeders as part of our ongoing crusher circuit maintenance and shutdown expertise, has enabled us to optimise certain features. These design features increase efficacy and ease of access improving maintenance processes while enhancing the safety of personnel and operators.

Innovative maintenance and safety features include:

• Segmented Sprockets for replacement without severing chains
• External Hydraulic Take-Up adjustment to allow adjustment without stoppage
• Integrated Lifting points for safer roller replacement
• Optional Composite Toolkit customized per machine
• Optional supply of purpose made Maintenance Platforms
• Optional Dribble Conveyor incorporated

Click here to view a video about our Apron Feeders.

Flexible Design Options

The Minprovise Apron Feeder Series is designed to conform to all AS/NZ standards while being able to accommodate design adjustments and adaptations to suit specific needs and requirements of our customers without compromise.

Possible adjustments include:

• Forged solid one-piece Head Drive Shafts
• Composite Shafts with keyed Sprocket Hubs
• Electro-Mechanical Drive Units
• Hydraulic Drive Units
• Single or Dual Drives
• Hydraulic Take-Up Adjusters
• Mechanical Take-Up Adjusters
• Optional Modular Skirt systems incorporated or adapted to suit clients existing design
• Optional Guarding incorporated

Locally Manufactured

Minprovise is a West Australian owned and operated company. Our Head Office and fabrication workshop is located in Welshpool, where the Apron Feeder range is manufactured. We aim to support local suppliers by sourcing components locally.

Apron Feeder Service & Support Capabilities

Minprovise’s Apron Feeder service and support capabilities include everything from Comprehensive Audits to complete refurbishments of the Apron Feeder and ancillary equipment. Our aim is to continually improve safety and identify efficiencies in processes, costs and improve downtime.

Audits

• Provide the client with an accurate position of the current condition of all the running gear and allows for the planning and procurement of long lead items
• Detailed report will highlight component and equipment condition and outline recommendations for ongoing maintenance and improvements

Maintenance

Minprovise are experienced specialists in the maintenance and servicing of Apron Feeders and associated ancillary equipment. We offer a complete and comprehensive service that covers:

• Design and Engineered drawings
• Project Management from Conception to Hand-over
• Initial inspection, planning and pre-engagement to ensure all options are covered and improvement methods investigated
• Provision of a full methodology SWP’s and Gantt
• A detailed report on work completed including, ITPs and any “Opportunities to Improve”
• Break-in works, as required
• Specialised tooling
• Technical Support and Advice

Click here to download our Apron Feeder brochure.

CONTACT US

To learn more about our Apron Feeders, fill out the contact form below and someone will be in touch shortly. Alternatively, call us on (08) 9359 6800 today.

Conveyor Components

CONVEYOR BELT MANUFACTURERS

Minprovise is a leading manufacturer for conveyor belts, parts and components across Australia. We place priority on efficiency and longevity in the production of our conveyor belt parts and components and with more than 15 years of supplying the mining, oil and gas industries, our conveyor belt manufacturers are dedicated to providing custom solutions that will best suit your industry’s demands.

CONVEYOR PARTS & COMPONENTS

Conveyors play a crucial role in industrial operations, improving efficiency and profitability. At Minprovise, we stock and manufacturer an extensive range of conveyor belt parts and components that ensure your conveyor system runs effectively. These components and parts are manufactured to the highest quality and have been tested in order to boost the efficiency and lifespan of your machinery. We also have a range of conveyor belt scale systems, conveyor safety systems, conveyor rollers and bearings and conveyor belt repair and protection products.

CONTACT US FOR CONVEYOR BELT MANUFACTURING TODAY

For conveyor belt parts and components manufacturer you can trust, speak with the team at Minprovise. We have a wealth of industry knowledge and experience with conveyor belt systems that sets us apart from other engineering and conveyor manufacturing companies. For more information on our conveyor belt components and parts, get in touch with us today.

Above Ground Fuel Tanks

MINPROVISE’s primary focus throughout our fuel tank design process is on achieving a premium fuel tank design at a competitive price point. This focus, in conjunction with Proleum’s end-to-end business model (providing the design, manufacture, transportation and install of tanks) allows for crucial savings to our clients and partners.

The tanks come in a full range of sizes, starting from 15 Kilolitres up to 200 Kilolitres.

Each fuel tank in our range comes with a multitude of additional features to ensure your site-based requirements are met. Such features include; Short or long walking platforms for larger tanks, safety cages, tailored ladder/stair systems and a range of base support options.

It is widely accepted that the cost and operational convenience of storing gasoline, diesel fuel and oil on-site is important to the efficient running of any oil, gas or mining facility. The savings on effective refueling processes and convenience of location are just a few reasons to consider this alternative, removing the unpredictability of public fueling locations and the appropriateness of fuel provided by external parties.

Contact Us at MINPROVISE to discuss your specific tank requirements and we can tailor our design and manufacture to your needs.

EziTite Headnut

Technofast Industries have successfully developed the EziTite^®  Hydraulic Head Nut System to replace standard mantle Head Nuts.

Since the development of the Gyratory Crusher, mineral processing industries have sought better means to effectively and safely tighten mantle head nuts. Technofast Industries have successfully developed the EziTite^®  Hydraulic Head Nut System to replace the outdated, standard mantle Head Nuts. In addition to technical and performance criteria, the major benefits of the design are focused on the protection of operators from strike or shrapnel injuries that commonly occur when hammering the standard mantle head nut tight. The EziTite^® features a hydraulic clamping nut and reinforced protective cover which can be constructed according to the abrasive nature of the material being crushed.

Tool Features:

• Precise clamping forces are generated by hydraulic pressure activation in the optimised containment area of the EziTite^® nut.  The Head Nuts are fitted with mechanical locking rings that retain these tensile loads. In the unlikely situation that there is a hydraulic malfunction, a simple, patented breaker-ring (that is positioned between the lock ring and the nut body) can be used to release the load on the shaft.

Benefits of the EziTite^®  Hydraulic Head Nut

• Vastly reduces downtime and maintenance problems
• Improves productivity
• Greatly enhances tool life
• Repeatable accuracy of the tensioning operation reduces product variation
• Achieves faster throughput without compromising product quality
• Minimises risk of personal injury and collateral damage to capital equipment during blade and tool changes
• Threaded locking collar counteracts loosening forces of impact on rotating shafts
• Requires low level of skill for operation

EziTite Hydraulic Nut

The EziTite^® Hydraulic Nut is a precision engineered, high pressure/high performance, hydraulically operated bolt tensioning device that can be quickly and easily fitted and used with Technofast pumping equipment.

The EziTite hydraulic nut is ideal for tensioning all of the studs on a flange, joint or cover – simultaneously loading 100% of the fasteners at once. This ensures an extremely accurate and balanced load onto the flange/joint.

EziTite Features:

• Reduces maintenance down time
• Improves safety on the job
• Gives reliable and precise tensioning
• Is user-friendly
• Fast to fit and remove
• Requires little physical effort
• Is ideal for difficult or confined spaces

The EziTite^® Hydraulic Nut is Ideal where:

• Accurate and reliable loading is required on bolting
• Vibrational or torsional stresses are a problem
• Regular maintenance requires repeated adjustment or removal of nuts
• There are confined or difficult nut locations

EziTite TR Hydraulic Nut

Tool Features:

• The patented metal-to-metal seal design allows for applications in temperature conditions upwards of 550˚C
• Compact Design for tight, confined applications
• Smart design to eliminate load losses
• Secondary backup release mechanism (Sacrificial ring)
• Multiple tensioning provides even bolt loads and short assembly/disassembly down time

Benefits of the EziTite^® TR Hydraulic Nut:

• Reduces maintenance down time
• Improves safety on the job
• Gives reliable and precise tensioning
• Is user-friendly
• Fast to fit and remove
• Requires little physical effort
• Is ideal for difficult or confined spaces

The EziTite^® Hydraulic Nut is Ideal for:

• Pressure Vessel Closure(i.e.: Autoclaves, Boilers, etc)
• Flange Makeup
• Gas Turbine Joints
• Steam Turbine Joints
• High Temperature applications

Clamp Nut

EziTite^® Hydraulic Clamp Nuts are the modern, safe and efficient way to ensure precise tool clamping.

EziTite^® Hydraulic Clamp Nuts replace conventional, torque-loaded threaded nuts to make shaft tensioning a simple, safe and efficient hydraulically assisted operation. They are also widely used to set large shaft bearings. Our Clamp Nuts are manufactured in a wide range of sizes to suit applications throughout many industries. EziTite^® Hydraulic Clamp Nuts are made in a standard range to suit thread sizes from 50mm to 300mm – additional sizes can be tailored by request.

 Tool Features:

• Vastly reduces downtime and maintenance problems
• Improves productivity
• Is user friendly, fast and easy to fit
• Greatly enhances tool life
• Repeatable accuracy of the tensioning operation reduces product variation
• Achieves faster throughput without compromising product quality
• Minimises risk of personal injury and collateral damage to capital equipment during blade and tool changes
• Threaded locking collar counteracts loosening forces of impact on rotating shafts

Benefits of EziTite^® Hydraulic Clamp Nuts:

• Accurate hydraulic loading
• Positive locking with mechanical ring
• Replaces lug wrench and hammer method
• Increases worker safety – decreases injury potential

EziTite^® Hydraulic Clamp Nuts are Ideal where:

• Accurate and reliable loading is required on bolting
• Vibrational or torsional stresses are a problem
• Regular maintenance requires repeated adjustment or removal of nuts
• There are confined or difficult nut locations

Cam Nut

Technofast’s revolutionary Cam Nut EziJac system creates an affordable and efficient solution, in a compact system that is simple, safe and easy to use.

Normally, Bolt Tensioning tools pull on the bolt threads protruding above the regular hex nut, which are then screwed down to retain the loads induced by hydraulic operation of the tool.  With no available thread, the Cam Nut performs as the connection to the bolt for the operation. Its integral collar expands to take up  the bolt’s elongation under force and retains the load when the hydraulic charging pressure is released.

 Tool Features:

User friendly, fast to fit & remove.

• • Requires little physical effort
  • Quick connection from nut to Tensioner
  • Ideal for situations with short bolt grip length
  • Modular construction reduces overall tool weight
  • Operating temperatures from –40 deg to +650 deg C

Benefits of using a Cam Nut:

• • No longer need to replace expensive studs to provide sufficient grip length
  • Modular construction reduces overall tool weight
  • Designed for extreme situations/adverse conditions
  • Minimises cost
  • Reduces downtime
  • Achievable reliable and precise tensioning the first time
  • User friendly to improve safety
  • Requires little physical effort
  • Fast to fit and remove
  • Reduce breakdowns and damage
  • Removes risk of strike and pinch point injuries caused by other tightening methods

A Cam Nut is Ideal where:

• • Regular maintenance requires repeated adjustment or removal of nuts
  • Speed of operation is essential
  • Bolts are of large diameter
  • Accurate and reliable loading is required on bolting
  • Space for tooling is restricted
  • Simultaneous tightening of bolts is required
  • Even joint/gasket compression is required

EziTite Hydraulic Bolts

EziTite® Hydraulic Bolts are precision engineered, high performance, hydraulically operated fasteners which incorporate mechanisms for tensioning. They can be quickly and easily fitted using standard pumping equipment such as Technofast’s hand operated, Electric or Air Hydraulic Pumps.

EziTite® Hydraulic Bolts minimise the time required to carry out critical bolting procedures and are extremely resistant to vibration and shock loads. They are specified and manufactured using alloy or stainless steels to suit application requirements. Protective covers or optional surface treatments are available.

EziTite® Hydraulic Bolt Features:

• Standard Range—20mm (7/8”) to 100mm (4”) bolt diameter
• Unique Lock-ring thread technology ensures maximum retained load
• Spherical seat gives alignment to joint face
• Variety of seal designs for temperature/pressure requirements
• Quick connect fittings

Benefits of the EziTite^® Hydraulic Bolt

• Stroke Indicator
• All standard Hydraulic Bolts fitted with CEJN type male snap fittings, 1/8″ BSPP porting and bleed plugs
• Hydraulic Bolts supplied with spherical washers as standard
• Hydraulic Bolts may be supplied with Nut and flat washer
• Maximum pressure of standard Hydraulic Bolts is 100 MPA (Custom designs may be higher)

The EziTite^® Hydraulic Bolt is Ideal where:

• Accurate and reliable loading is required on bolting
• Vibrational or torsional stresses are a problem
• Regular maintenance requires repeated adjustment or removal of fasteners
• Fasteners may be in confined or in difficult locations
• Applications may include: Vibrating Screens and Sieves, Piping Flanges, Reactor Joints and Covers, Autoclaves and or Foundation Bolts.

Rice Lake Master Belt Scale Systems

We proudly supply Rice Lake Master Belt Scale Systems; these precision systems are designed to meet high accuracy requirements. They enable monitoring of production output and stockpile inventory, while regulating product loadout. This vital data supports optimised business management and efficient operations.

https://www.ricelake.com/product-landing-pages/belt-scale-systems/

Rice Lake Master Range of Products available from Minprovise

Contact our Sales team today to get your project otimised with the right products.

Megapoxy Crusher Backing Products

Australia’s leading brand of Epoxies and crusher backing now available here!

Discover Megapoxy, Australia’s leading brand of epoxy and crusher backing, Manufactured in New South Wales, and now available through Minprovise!

You might need Megapoxy 57 Slow, a high strength, pre-filled, solvent free epoxy grout designed for applications in higher temperature ranges and for deep casting situations. Or Megapoxy High Impact Crusher Backing might be better suited to your crusher needs. This is a two-component pourable epoxy grout.

Trust Megapoxy Crusher Backing for unrivaled crusher protection. Formulated with high-strength epoxy, it reinforces wear surfaces, enhancing performance and slashing downtime. Australia’s leading brand, now available through Minprovise

Talk to our Sales Team about which one is best for your site.

Crusher Backing available here

https://www.permatech.com.au/megapoxy.html

FastJac

Technofast’s FastaJac saves on Production, Labor and Maintenance Costs for Manufacturers and End Users of Plate Heat Exchangers.

The use of a lightweight hollow cylinder jack, in conjunction with the patented ‘Tri Nut’, allows the compression of plates to be  carried out evenly, squarely and efficiently. The hydraulic cylinders simultaneously compress the plates. The Tri-Nut is designed to fit over the major diameter of the thread until it engages into it’s spherical seat. Then the nut closes onto the thread and the nut is screwed home as normal. This facilitates speedy fitting and removal of the tools  removing the need for ‘running down’ the Tensioner retaining nut over the full length of the thread.

Tool Features:

• The Patented ‘Tri Nut’ allows the Tensioner to be removed and installed on the exchanger quickly
• The hydraulic cylinders simultaneously compress the plates so the compression of plates are carried out evenly, squarely and efficiently
•  Unique cam lock design
• Tri Nut locks into tool, even in upside down position
• Quick connect fittings
• No Pinch Points

Y2 & X2 – 2 Stage Tensioning

Technofast’s X2 & Y2 2-Stage EziJacs encompass a large range of slim bodied tensioners to complete maintenance on any application with restricted space.

The 2-Stage series of hydraulic Tensioners are a lightweight, user friendly range of Tensioners, which are quickly and easily fitted in restricted spaces. These Tensioners are powerful & provide accurate and versatile tensioning of bolts and studs, whilst being fast, simple and safe to use.

Tool Features:

• Stroke Indicator
• Long Stroke
• Spring return piston
• Over stroke prevention
• Slim fit design
• Leak-free, low-friction seals
• Nitrated components
• Optional side gear box
• Quality assured

Technofast’s X2 and Y2 Multistage Bolt Tensioners may be fitted with an optional Gear Drive to rotate the retaining nut without the use of a Pin Spanner. The drive is operated using a standard 1/2″ socket wrench. The feature optimises the speed of operation and allows the tools to be used in restricted spaces where a Pin Spanner drive could not be employed. An Integral idler gear is used to ensure that the drive tool and nut rotations are in the same direction.

B3M EziJac Bolt Tensioner

The EziJac uses hydraulic pressure to tension the bolt to the exact load required. Once the bolt has been tensioned, the nut is wound down the thread to retain the load. The EziJac is then de-pressurised, released and ready to use again.

Tool Features:

• Stroke indicator
• Long Stroke
• Interchangeable Adaptor Kits
• Leak-free, low-friction seals
• Nitrated components to increase the tool life
• Optional second port
• Quality assured

Benefits of a B3 Series EziJac:

• Reduce assembly time for critical jointing applications
• Multi-point tensioning for even gasket compression
• Reduced labour input
• Requires little physical effort
• Improves safety on the job by eliminating hammer tightening
• No pinch points – Unlike power wrenches
• Remote pumping – No operators in close work area
• User friendly; fast to fit and remove

 The B3M EziJac is Ideal where:

• Accurate and repeatable loading is required
• Irrational or torsional stresses are a problem
• Regular maintenance requires repeated adjustments or removal of nuts
• Confined and difficult nut locations
• Simultaneous tensioning of bolts is required (eg: Flanges)

B3S EziJac Bolt Tensioner

Safe, Easy-to-operate and built with Spring Return – This Product ensures only the most accurate of Bolt Tensioning.

The B3S EziJac uses hydraulic pressure to tension the bolt to the exact load required. Once the bolt has been tensioned, the nut is wound down the thread to retain the load. The EziJac is then depressurised, released and ready to use again.

Tool Features:

• Stroke indicator
• Long Stroke
• Spring return piston
• Interchangeable Adaptor Kits
• Leak-free, low-friction seals
• Nitrated components to increase the tool life
• Optional second port
• Quality assured

Benefits of a B3 Series EziJac:

• Reduce assembly time for critical jointing applications
• Multi-point tensioning for even gasket compression
• Reduced labour input
• Requires little physical effort
• Improves safety on the job by eliminating hammer tightening
• No pinch points – Unlike power wrenches
• Remote pumping – No operators in close work area
• User friendly; fast to fit and remove.
• Spring Return models for automatic retraction

 The B3S EziJac is Ideal where:

• Accurate and repeatable loading is required
• Irrational or torsional stresses are a problem
• Regular maintenance requires repeated adjustments or removal of nuts
• Confined and difficult nut locations
• Simultaneous tensioning of bolts is required (eg: Flanges)

B2 EziJac Bolt Tensioner

The B2 EziJac Stud Tensioner utilizes the power of hydraulic pressure to produce the force necessary to tension bolts and studs accurately & safely.  The B2 EziJac Dedicated Stud Tensioners provide the answer to many of the fitting problems associated with using larger tensioning equipment. They are also ideal for single task applications which do not require interchangeability of thread sizes. Any number of B2 EziJacs can be interlinked to provide simultaneous tension over multiple studs or bolts as required

Tool Features:

• Stroke Indicator
• Long Stroke
• Leak-free, Low-friction seals
• Nitrated components to increase the tool life
• Manual return
• Optional second port
• Quality assured

Benefits of B2 EziJac

• Reduces maintenance down time
• Improves safety on the job by eliminating hammer tightening
• Reliable and precise tensioning
• Is user friendly – fast to fit and remove
• Requires little physical effort
• Ideal for confined spaces or difficult locations

The B2 EziJac is Ideal where:

• Accurate and repeatable loading is required
• Irrational or torsional stresses are a problem
• Regular maintenance requires repeated adjustments or removal of nuts
• Confined and difficult nut locations
• Simultaneous tensioning of bolts is required (eg: Flanges)

Premium Crusher Backing – Megapoxy

Megapoxy 57 Slow and HICB

Megapoxy is Australia’s leading brand of epoxy. Manufactured in New South Wales, there is a large range of epoxies to suit a variety of industries.

Megapoxy 57 Slow is a high strength, pre-filled, solvent free epoxy grout designed for applications in higher temperature ranges and for deep casting situations. It has a high flow rate and can be applied into narrow gaps down to 4mm if required.  In addition,  Megapoxy 57 Slow has a very high resistance to chemicals allowing it to be used for machinery in chemical processing plants.

Megapoxy High Impact Crusher Backing is a two-component pourable epoxy grout.

https://www.permatech.com.au/megapoxy.html

Applications

The construction grouts we supply can be used for the following applications:

• Crusher Backing
• Vertical grouting of starter bars
• Machine or column bed grouts
• General purpose pourable grout

Megapoxy products can be purchased in 1, 5 and 10 kg kits. If you’re unsure of what size kit you need for your crusher backing, vertical grouting, machine grout, column grout, or just general-purpose grout, contact our Sales Team who can provide you with expert advice and more.

Dugless 903 Remote Control Mini Loader

Designed and built by Minprovise, the Dugless 903 is an automated digging and cleaning unit. It’s capable of maneuvering under low conveyor sections and other inaccessible places. This results in cleanups without shutdowns. Created specifically as a safe, and cost-effective solution for the mining industry. The low-profile design enables easy access underneath conveyor systems to remove material without risk to workers, equipment or the need to shut down. Because of this, Mining isn’t the only industry adding the Dugless 903 to their mobile assets.

For more information, to see a demo or request a quote, contact our expert team today at sales@minprovise.com.au

Dugless 903 White Paper

BENEFITS OF THE DUGLESS 903

• • No shutdowns required for cleanups
  • Easily accesses most low ground clearance conveyor frames
  • No manual labour needed, remove tonnes of material by remote control
  • Improved safety, lower accident risk
  • Improved productivity
  • Greater cost-efficiency
  • Designed to prevent drive machinery breakdowns

FEATURES OF THE DUGLESS 903

• WA designed and manufactured
• Remote controlled
• Simple 2 joystick hand remote harness
• Only 560mm tall
• Self-levelling 4 in 1 bucket heaped capacity of 0.13m3
• Upgraded 8-chamber Cyclone Design Airbox

Click here for details about the Dugless 900 Airbox Upgrade to 903

ACHIEVEMENTS OF THE DUGLESS 903

Since its launch, the Dugless series has proven its success globally to the mining and bulk material handling industries. In 2009, the year the Dugless 900 launched, the unit won:

• Winner of Bulk Materials Handling Award – London’s Mining Magazine
• Winner of Best Practice in OH&S Category – 4th Australian Bulk Handling Awards
• Finalist in the Innovative Mining Solutions Category – 6th Annual Mining Prospect Awards

The machine has since had the airbox upgraded, decreasing filter changeouts and extending engine life and nonstop operating hours.  Which is why the DUGLESS 900 and upgraded 903 model have proven their success in mining & other industries.

CONTACT US

For more information, to book a demo or request a quote for the  Dugless 903 fill out the contact form below and we’ll will be in touch shortly. Alternatively, call us on (08) 9359 6800 today and come and see it for yourself at our WA Welshpool workshop.

Thermo Scientific Ramsey Series 17 Discontinued

Ramsey Series 17

This product has been discontinued – effective June 26, 2023. However, we offer aftermarket support including remote technical support and some field service, as well as ThermoFisher Scientific spare parts based on material availability.

Minprovise has been appointed as official distributors of Rice Lake Master products. See our full range by clicking the link below or contact our Sales Team.

Rice Lake Master Premium Bulk Weighing and Monitoring Solutions here

Thermo Scientific Ramsey Series 14 Discontinued

Belt Scale Systems – Thermo Scientific Ramsey Series 14

This product has been discontinued – effective June 26, 2023. However, we offer aftermarket support including remote technical support and some field service, as well as ThermoFisher Scientific spare parts based on material availability.

Minprovise has been appointed as official distributors of Rice Lake Master products. See our full range by clicking the link below or contact our Sales Team.

Rice Lake Master Premium Bulk Weighing and Monitoring Solutions here

 http://Precision Belt Scale Systems BS14-products-Minprovise – Minprovise

Thermo Scientific Ramsey IDEA

The Thermo Scientific™ Ramsey™ IDEA belt scale system provides basic rate information and totalization functions in processes requiring an accuracy of ±1%. This belt scale system allows you to monitor production output and inventory, or regulate product loadout, while providing vital information for the effective management and efficient operation of your business.

Features

• Economical and accurate
• Factory installed and calibrated overload protection
• Pivotless design with no linkages to introduce errors
• No moving or wearing parts to cause potential maintenance problems
• Compact design for easy installation and alignment
• No place for material to build up and cause measurement errors
• Identical scale modules fit on any belt width and are interchangeable

Specifically designed for operations where economy and ease of installation are important considerations, the Ramsey IDEA belt scale system is ideally suited for applications in processes involving either non-critical or lower value materials.

Thermo Scientific DDG3 Digital Density Gauge

The Thermo Scientific™ DDG3 Digital Density Gauge is a non-intrusive, non-contact device for accurate density or percent solids measurement for liquids and slurries flowing in a pipe. Equipped with a range of communication protocols, it is especially suitable for applications involving highly toxic, highly corrosive materials or processes operating at elevated temperature. The DDG3 is easy to install and used across the mineral processing, petrochemical, coal, food, water treatment, and pulp/paper industries to support efficient process control and optimize productivity.

Thermo Scientific Ramsey Mercury-Free Tilt Sensor

The Thermo Scientific™ Ramsey™ Mercury-Free Tilt Sensor is a rugged, abrasion-resistant solution for the detection of materials handling problems. Actuated when materials rise to tilt the probe by 15o or more, in any direction, it replicates the performance of traditional mercury-based technology while simultaneously reducing health and safety concerns. Measurements are jitter-free, stable, and highly sensitive. Choose from a variety of probe assemblies to match specific process materials and environmental conditions – including options for use in hazardous areas – to efficiently detect problems such as high and low level, chute blockage, and sub-optimal material flow.

Thermo Scientific Ramsey C-Level

Eliminate failure and maintenance issues with your inventory monitoring and process control system with the Thermo Scientific™ Ramsey™ C-Level Continuous Level Indicator. Ideally suited for bulk solids or liquids, the Ramsey C-Level Continuous Level Indicator monitors inventory and process control during load-out or filling. With its unique precision strain gauge sensors press-fit into the support structure, the Ramsey C-Level Continuous Level Indicator can operate without concern for failure or maintenance issues caused by the monitored material or process environment. This distinctive design also compensates for temperature changes that can affect the accuracy of bolt-on strain sensors.

ZI Cone Crusher – in stock now

If you are wanting to increase plant capacity and improve product shape, the ZI Cone Crusher Series delivers.

EarthTechnica, the crushing equipment division of Kawasaki Heavy Industries, have developed the ZI-series cone crusher to incorporate all the key benefits of the successful Kawasaki CYBAS Cone design, with added features to achieve increased performance within the same body sizes.

The crushing members of the ZI CONE are a combination of a mantle, concave with grooves, and special mild inserts (MSI). This arrangement leads to compound crushing, consisting of not only compression, but also crushing through bending and shearing actions. The synergy of this compound and high-density inter-particle crushing within the main chamber, results in superior results with large feed capacities while using less energy.

See the ZI-2100 demonstrated at our Main Workshop in Welshpool, WA. Contact us today to arrange a viewing. The ZI Cone Crusher is now available for purchase.

Features of the ZI Cone Crushing Equipment

High Crushing Capacity

The high capacity of the ZI Cone’s crushing chamber, coupled with its combined crushing effect, results in a remarkable improvement in crushing capacity.

High Set Under Ratio and Professional Shape

The bisector line of the ZI crushing chamber is almost vertical at the inlet. Its angle of inclination changes gradually until it reaches a specific angle at the outlet. Accordingly, the density of the feed material is increased as it proceeds from the inlet towards the outlet. This causes inter-particle crushing due to the high density in the crushing chamber. As a result, a product with roundish cubic shape can be produced, with high set under ratio.

Lower Energy Cost

The ZI Cone Crusher performs combined crushing through bending, shearing and compressing actions of its grooved crushing plates, as compared to conventional crushers that use compression only. This leads to a more efficient power output, which in turn leads to considerable energy savings.

Easy Adjustment of Discharge Setting

The ZI’s hydraulic system provides easy discharge settings, even during operation, through it’s easy-use control panel. These adjustments can also be remotely controlled.

Easy and Safe Maintenance

The inside of the ZI crusher can be easily checked through its large inspection windows located on its bottom frame. A Special torch ring enables the easy and quick replacement of the liners in a short time while the head nut for its mantle can be used repeatedly.

Click here to see the Active Gap Control System working with the ZI Cone Crusher.

Click here to read about how the ZI Series works with Active Gap Control System.

Gyratory Crusher (GY Model)

Gyratory, Cone, Impact & Jaw Crushers for Sale

At Minprovise, we’re the specialists in providing quality cone, jaw and impact crushers to the mining, oil and gas and construction industries throughout Australia and internationally. Our crushing equipment, including gyratory crushers, are sourced from Earthtechnica, which includes internationally recognised manufacturers of crushers, Kobe and Kawasaki. Find out more about our range crushing equipment we have for sale below.

Features of the GY Gyratory Crusher:

The excellent design of the Gyratory Crusher is only one of the reasons the team at Minprovise recommend this model when choosing crusher equipment. The GY’s design is a combination of some of the world’s most modern engineering techniques and applications. Earthtechnica’s newest 60-109 GY can be divided into several smaller parts, which makes it easy and cost-effective to transport and install. Each of these individual parts for the GY crusher, are built for endurance and long-life wear.

Created by one of the Industry Leaders in Crushing Equipment

With more than 80 years of experience within the crushing equipment industry, Earthtechnica have supplied more than 120 gyrator crushers to mines and quarries worldwide. Through their strategic partnership with our team at Minprovise, we’re able bring this experience and industry leading equipment to the Australian market.

Gyratory Crusher (KG Model)

Features of the Gyratory KG Crushing Equipment:

The KG crusher features a simple discharge set, making it an efficient solution for your business. The discharge setting on this model is simple and can easily be adjusted by the amount of oil in the hydraulic cylinder installed at the bottom of the main shaft.

Main Shaft Collapse Prevention

If hard ore enters the crushing chamber, the main shaft may develop a jumping action. To prevent the main shaft from falling down, the hydraulic support for the main shaft is maintained by raising a piston within the balance cylinder, which contains air and oil.

Re-start Capability while Loaded

If the crusher stops unexpectedly during its procedure and the raw material inside needs to be removed from the crushing chamber, the KG’s hydraulic system will accommodate this. It does this by lowering its crushing head in order to discharge the wedged ore, allowing for immediate restart.

Heavy Duty Spider Bearing

The KG’s large spherical bearing is equipped with a spider bearing to reinforce it for continuous heavy strain and long life.

HPC Cone Crusher

High Pressure and Performance Crushing Equipment

The HPC Cone Crusher has been designed and developed to achieve a high crushing ratio and high through-put capacity, with its newly designed crushing chamber. This chamber achieves this by increasing the density of feed material from inlet to outlet as the materials are crushed under high pressure.

The robust design of the crusher body is reinforced to withstand high pressure crushing, and to ensure that the crusher equipment can be operated under heavy operating conditions for long periods of time.

If you’re looking for a cone crusher for sale, the team at Minprovise can help. Contact our expert team to find out more about our wide range of crushers including, Kawasaki and Kobe crushers.

Features of the HPC Cone Crusher

Crushing Equipment with High Performance

HPC curved crushing chamber provides a high level of performance. The bisector line is vertical at the inlet of the crushing chamber, with a gradual slant from inlet to outlet. This design ensures the gravitational push of feed materials downwards into the crushing chamber at an economical and efficient rate, increasing not only your through-put capacity, but also your high set-under ratio. The performance of the cone crusher is one of main reasons we offer this equipment for sale at Minprovise.

Endurance of Performance

In the case of conventional cone crushers, usually the inlet width of the crushing chamber decreases through the constant wear of its crushing members. In the case of Earthtechnica’s HPC, the upper region of its crushing parts is especially reinforced with a unique groove, this ensures the even wear of its parts from inlet to outlet.

Wide Inlet of Crushing Chamber

The configuration of the upper part of the HPC concave is an inverse cone which provides a wide inlet into the crushing chamber. The HPC can receive very flat and long materials without bridging, allowing the crusher to be used as a substitute for the secondary gyratory crushers.

Robust Body Design

The HPC is specifically designed for the body to withstand continuous heavy loads of feed materials that are also robust and strong in nature – especially iron ore.

Astro Jaw-E Crusher

Features of the Astro Jaw-E Crushing Equipment

Large Crushing Capacity with New “V” Chamber Design

The newly designed “V-shape” crushing chamber ensures the Jaw Crushers ability to withstand large capacities of feed material, while Its reversible, corrugated jaw plates create a non-choke configuration. This crusher is manufactured by Earthtechnica, which includes Kobe and Kawasaki.

Strong Body Design

This crusher is fully fabricated with a stress-reinforced, one-piece frame and swing-jaw, both of which are built to last and go the hard yards.

Easy Maintenance

The Astro comes with a set-adjusting device which cuts lead times in half. Its jaw plates retain their position through bolted wedges while spherical roller bearings with labyrinth seals prevent the ingress of dust.

Super Sander (KMC)

Sand Making Impact Crusher

The Super Sander is a specialist machine, designed for dry crushing and grinding for sand production. Flaky materials are crushed and ground down to a superior product shape.

Feed material is constantly fed into the crushing and grinding chamber, which is formed through the unique combination of grinding path and inter-particle crushing components. This process achieves a product size and quality comparable to natural sand.

Super Impeller (KIS)

Features of the Super Impeller:

Excellent Product Shape

Excellent grain forms are achieved by the adoption of this crushers special grinding path system and its improvements to impact and grinding operations. Additionally, the machine is capable of producing reduced material sizes as a result of its high reduction ratio.

Easy Maintenance

The Super Impeller’s boltless system makes the fixing or replacement of its striking blades and grinding path liners simple and efficient, while also ensuring that its daily maintenance and control is front of mind with ease.

Easy Adjustment of the Discharge Opening

The variability of adjustment to the discharge opening and grinding path are made practical and simple through this crushers unique hydraulic cylinder.

Impeller Breaker (KAP/SAP)

Features of the Impeller Breaker:

Greater Crushing Ratio

A high crushing ratio of 10-3 (compared to the 5-3 of conventional gyrators, cone or roll crushers) effectively eliminates several crushing processes from more basic crushing systems.

Cubical Products

Compared to compression crushers, the Impeller Breaker produces much higher quality cubical products – ensuring greater savings for mortar than the aggregate of other machines crushing concrete of equal strength.

Selective Crushing Capacity and Uniform Product Size

Because of the lack of binding force, feed materials can be separated into their various elemental components. The size or shape of these material feeds also has no influence whatsoever on the final product size.

Low Power Consumption and Minimum Installation Costs

As an impact crusher, the greatest portion of power transmitted to the rotor is used purely for crushing. As this machine is compact, yet powerful, the impeller breaker requires little space. Vibration-free operation means simpler, less costly foundations.

Safety with Foreign Materials and Easy Maintenance

If foreign materials enter the crusher, the impact plate ensures this unwanted material is quickly discharged. The Impeller Breaker is so well designed and manufactured that no operator training is required to operate it. The crusher has simple usage instructions.

Luwirep 70

Luwirep 70, For Fast Conveyor Belt Repair & Wear Protection

The Luwirep 70 is designed for the fast repair of rubber conveyor belts and wear protection. This 2-component repair material was developed by LUTZE, especially for damaged rubber conveyor belts.

The adhesion and abrasion on this system were optimised to the rubber’s characteristics. Conveniently, the Luwirep 70 can repair damages in as little as 40 minutes, and the conveyor is operational immediately once completed.

Applications for Conveyor Belt & Wear Protection Repair

The Luwirep 70 is compatible with all common scraper and belt cleaning systems and is suitable for a variety of applications where repairs are required. Find out about the appropriate applications for this system below.

• Repairing of cover rubber damages of fabric and steel cord conveyor belts.
• Compatible with all common scraper and belt cleaning systems.
• Covering mechanical fasteners.
• Restoring extremely stressed areas.
• Sealing plate seams of installed linings.

Advantages

The Luwirep 70 allows you to repair your conveyor belt efficiently, minimising the downtime of your conveyor, helping you to get back to work sooner. Find out more about the advantages of the system below.

• Only small tools required.
• Fast and clean processing.
• Fastest curing time.
• Minimum downtime of your conveyor.
• Simple handling, even for inexperienced users.
• Applicable in hard-to-reach locations.
• Perfectly adjusted to rubber characteristics.
• Cartridges can be closed after being opened.
• Good adhesion on nearly every material.

Please ask for special primers for your application.

Luwirep 85

The Luwirep 85 For PU Wear Protection Repairs

The Luwirep 85 is ideal for filling seams, as well as transitions of bolted or bonded Luwitan plates, and other lining materials. Due to the superb abrasion characteristics, it can also be used for strengthening heavily stressed areas.

The material is processible for approximately 10 minutes and can be mechanically finished after hardening.

Applications of The Luwirep 85 Repair System

This system can be used for a variety of applications where repairs on PU wear protection is required. A full list of the applications it can be used for can be found below.

• Sealing plate seams of installed linings.
• Equalising of transitions.
• Strengthening of heavily stressed areas.
• Repairing conveyor belt damage.

Advantages

• Only small tools required
• Excellent wear resistance
• Fast reaction time
• Also applicable in vertical and over-head situations
• Good adhesion on nearly every material
• (please ask for special primers for your application)

Contact Us

To learn more about the Luwirep 70 and 85 repair systems fill out the contact form below. Alternatively, contact us on (08) 9359 6800 today.

Compound Crusher (AP-C)

Primary Impact Crusher – Double Rotor

The Compound Crusher is a double-rotary, primary impact crusher, which functions as both a primary and secondary crusher. Find out more about the Compound Impact Crusher we have for sale below.

Features of the Compound Crusher Equipment

High Reduction Ratio and Capacity

With its high capacity crushing chamber, fixed striking blade and single grinding path arranged effectively around its rotor, this compound crusher is optimised to achieve high reduction ratios while taking on large capacities of feed material. These materials can then be fed to the ball mill without the need for any secondary crushing.

Robust and Reliable Design

It’s simple robust design and rotor creating strong inertia forces allows this crusher to withstand heavy-duty use with reliable durability.

Easy Maintenance and Operation

The compound crusher is equipped with a fully hydraulic system which allows for easy and adjustable product sizing and maintenance. Large inspection hatches are engineered to all faces of the machine.

Luwispray Spray Coating

Our highly elastic coating materials for wear and surface protection ensure that system components, vehicles, mixers, mills, cyclones, etc. last that much longer. PU spray coatings are particularly suitable for wear and tear through sliding abrasion, often in conjunction with a chemical exposure. The required layer thickness is chosen depending on the application and is at least 2 mm.

Uses

• Lining of coal, ore and sand bunkers and dust collectors
• Corrosion protection for system parts
• Silo and tank linings
• Screw conveyors and screens
• Conveying equipment
• Chutes and slides
• Pipe linings
• Vibratory grinding container
• Mixer and shaker
• Pump parts and cyclones

LUWISPRAY spray coatings are distinguished by the following:

• Highly resistant to wear
• Age-resistant
• Impact-resistant
• Chemical-resistant
• Crack-bridging
• Permanently elastic
• Hydrolysis-resistant
• Seamless

Super Breaker (KSB)

Primary Impact Crusher

The Super Breaker is an impact crusher with a single rotor, specially designed for primary crusher use in cement plants. Earthtechnica’s experienced technology makes it possible to feed the materials directly to the roller mill without any secondary crushing required. The Super Breaker will help your company increase its productivity and profit.

Features of the Super Breaker

High Reduction Ratio and Capacity

With a high capacity crushing chamber, fixed striking blade, two impact plates and one grinding path, all arranged effectively around the rotor, the Super Breaker is optimised to achieve high reduction ratios and capacities. The materials can be fed to the roller mill without the need for any secondary crushing.

Tough and Reliable

It’s simple and robust design, combined with its large force of inertia allow for this crusher to withstand ongoing heavy-duty use with guaranteed reliability.

Cost Efficient

Installing just one Super Breaker can make your crushing system simpler, while reducing the total amount of power required throughout your processes, minimising your operation costs. It’s striking blade and other important wear parts are fabricated with high quality, wear resistant steel castings.

Contact Us

If you’re looking for a Kawasaki or Kobe crusher, look no further than Minprovise. To find out more about the wide range of cone, jaw and impact crusher equipment we have for sale, get in touch with our experienced team by filling out the contact form below.
